No. | Item | Parameters |
1 | Display screen size | 480*1120mm |
2 | Product model | FS5 |
3 | Dot pitch | P5 |
4 | Pixel density | 40000 |
5 | LED bulb | 1R1G1B |
6 | LED bulb model | SMD1921 |
7 | Model size | 160*160mm |
8 | Module Resolution | 32*32Px |
9 | Driving mode | 1/8 scans |
10 | visual angle(Deg) | H:140/V:140 |
11 | brightness | 5500 (cd/㎡) |
12 | Grayscale | 14bit |
13 | refresh frequency | 1920Hz |
14 | Power consumption(W/㎡) | Max:760/ Average:260 |
15 | Life span | 100000hours |
16 | working voltage | AC 110V~220V+/-10% |
17 | Frame change frequency | 60Hz |
18 | Degree of protection | IP65 |
19 | working temperature | -30℃--+60℃ |
20 | Working humidity(RH) | 10%-95% |
21 | Product certification | CCC、CE、ROHS |
